OneOf

Introduction

OneOf is a container widget that can hold one of several child widgets, such as Radio, Select, or Switch. Depending on the value selected by the user within these child widgets, the corresponding item will be added to the page markup. It is very convenient to quickly switch between different items without losing sight of the overall picture.

Function signature

one_of = OneOf(
    conditional_widget=Select(items=animals),
    widget_id=None
)

Parameters

Parameters	Type	Description
conditional_widget	ConditionalWidget	conditional widget with preset items (Select, RadioButton, Switch)
widget_id	str	ID of the widget

conditional_widget

Conditional widget with preset items.

type: ConditionalWidget

# prepare "animals" using RadioGroup.Item
one_of = OneOf(
    conditional_widget=RadioGroup(items=animals)
)

widget_id

ID of the widget.

type: str

default value: None

Mini App Example

You can find this example in our Github repository:

ui-widgets-demos/layoutsnand containers/008_one_of/src/main.py

Import libraries

import os

import supervisely as sly
from dotenv import load_dotenv
from supervisely.app.widgets import Card, Container, OneOf, Select, Image

Init API client

First, we load environment variables with credentials and init API for communicating with Supervisely Instance:

load_dotenv("local.env")
load_dotenv(os.path.expanduser("~/supervisely.env"))

api = sly.Api()

Prepare conditional widget content

You can use RadioGroup, Select or Switch widgets to set in conditional_widget parameter. In this tutorial we will use Select widget.

Prepare sample images

image_1 = Image(
    url="https://user-images.githubusercontent.com/79905215/218269544-2e126d4a-20eb-4ace-8933-d36732bb0634.jpeg"
)
image_2 = Image(
    url="https://user-images.githubusercontent.com/79905215/218269547-5b5316f9-9ae2-4b0c-aedb-b2238e44f95d.jpeg"
)
image_3 = Image(
    url="https://user-images.githubusercontent.com/79905215/218269550-a5caba65-1f0f-4986-8711-7d36c7911e51.jpeg"
)

Prepare items for Select widget using Select.Item

items = [
    Select.Item(value="image 1", label="image 1", content=image_1),
    Select.Item(value="image 2", label="image 2", content=image_2),
    Select.Item(value="image 3", label="image 3", content=image_3),
]

Create Select widget.

select_items = Select(items=items)

Initialize OneOf widget

one_of = OneOf(conditional_widget=select_items)

Create app layout

Prepare a layout for app using Card widget with the content parameter and place widget that we've just created in the Container widget.

card = Card(
    title="One of",
    content=Container(widgets=[select_items, one_of]),
)

layout = Container(widgets=[card])

Create app using layout

Create an app object with layout parameter.

app = sly.Application(layout=layout)
